PAR Sensor

TF6017

The sensor measures radiation within the photosynthetic relevant spectrum. The sensitivity corresponds with the optimum efficiency of chlorophyll. The measuring results enable a reliable assessment of development conditions of plants. This sensor is used in the areas of agriculture, agriculture research, horticulture and education.

The photochemical develop processes of plants in open areas and greenhouses can be optimized with the help of the PAR sensor. The sensor consists of a weather protected aluminium housing with an UV permeable plastic dome. The measurement is cosinus corrected.

  • Technical Specification
  • Variations
  • Measuring range: 0...ca. 250 W/m²
  • spectral Sensitivity: 380...700 nm
  • max.spectr. Sensitivity at: 420 nm and 600 nm
  • Operating temperature: -20...+60 °C
  • Output: 0...5 V or 0/4...20 mA
  • Power supply: +9...+30 VDC
  • note 6017.0000PAR Sensor, with PMMA Dom, Output 0...5 V
  • note 6017.1000PAR Sensor, with PMMA Dom, Output 4...20 mA
